Tile cutting machine common failure

Common faults of ceramic tile cutting machine: cutting line is not straight, ceramic tile is not with the knife, and the mark is split. Broken tiles, crooked edges, or jagged. The measuring ruler is not allowed, and the tile is missing corners when cutting.

Therefore, the elimination method of the cause of the obstacle

1, shaft rail deformation; 1, re-press or replace the spindle;

The cutting line is not straight 2, the bearing on both sides of the cutting head is too loose; 2, tighten both sides of the bearing;

3, the blade device is not correct; 3. Correct the blade device

4, blade deformation. 4. Replace the blade.

1, the blade is too blunt or the cutting force is not uniform; 1. Replace the blade

2, the platform element pin deformation; 2. Calibration platform;

3, pressure foot deformation; 3, correct the press foot;

4, tile quality problems. 4. Try another ceramic.

1. Uneven press foot of ceramic tile fracture; 1, correct the press foot;

The brick edge is not correct 2, the guide rail seat deformation 2, replace the guide rail seat;

3, the use of excessive pressure when cutting; 3, reduce the pressure to promote the current force;

4, tile quality problems. 4. Try another ceramic.

1. The blade device is loose; 1. Reset the tool head;

2, measuring scale deformation; 2, replace the measuring scale or another calibration;

3. Reverse adjustment rod; 3, adjust back the ruler rod;

4, blade damage; 4. Replace the blade;

5. The bearing on both sides of the cutting head is too loose; 5, tighten both sides of the bearing.

Ceramic tile missing corners when cutting 1, press foot damage; 1, replace the press foot;

2. Asymmetrical guide rail; 2. Correct the guide rail;

3, ceramic tile quality problems. 3. Try replacing other ceramics.

Precautions and use tips:

1, when cutting, drag the "handle" to the highest control position to avoid collision between the blade and the tile, otherwise, the blade will not be used due to defects.

2, for antique or other convex and concave tiles, please replace the cutter head! Rough surface tiles will shorten the service life of the blade.

3, do not use the blade to press the broken brick in the operation.

4. When cutting, first pull the push rod to the back end, let the blade press gently on the tile, push forward along the spindle to the front control groove, put the press foot on the tile, gently hit the end of the push and pull handle, the tile can be broken with the knife mark

Warm reminder: in the cutting process, when the knife mark cutting line is thinner and shallower, the tile press the split brick edge shape is more beautiful. On the contrary, the deeper and thicker the knife mark line, the more inclined the bottom shape of the brick side split the more crooked, even like jagged when serious, so the force must be light when pushing, but the cutting mark line on the tile can not be interrupted, otherwise the tile will appear bounding Angle phenomenon.
