Stone cutting machine installation method

1, first place two parallel rails on the ground. Its width is equal to the width of the cutting frame walking wheel.

2. Put the frame on the parallel track, and move back and forth completely with the track and move freely.

3. Put the stone cutter main machine on the frame, the four rollers on the main machine should be completely consistent with the channel steel on the frame, and the movement direction of the main machine after being put into a 90-degree cross with the movement direction of the frame and their respective movements are free.

4. Install the power, so that the motor is firmly connected with the main engine through the motor leg, and the motor axis direction is horizontally and vertically crossed with the main engine direction.

5. Install the belt

6. Install the guard.

7, starting motor, check the saw blade axis rotation direction and the direction indicated by the shield arrow.

8. Install the saw blade. Connect the water pipe.
